CIXI Ultrasonic Level Meter Water Tank Level Sensor Oil River Ultrasonic Level Transmitter Level Measurement Liquid Level Sensor Two Wire or Three Wire
Default 4-20mah, support customization, can be customized to add High And Low Level Alarm High And Low Level Alarm, Explosion Proof (EX) Explosion Proof (EX), anti-corrosion, 220V, etc.
The ultrasonic level mete is a digital level gauge controlled by a microprocessor. In the measurement, the ultrasonic pulse is emitted by the sensor (transducer), and the sound wave is reflected by the liquid surface and received by the same sensor or ultrasonic receiver, converted into an electrical signal by a piezoelectric crystal or magnetostrictive device, and transmitted and received by the sound wave To calculate the distance between the sensor and the surface of the liquid being measured
Due to the non-contact measurement, the measured medium is almost unlimited, and it can be widely used for measuring the height of various liquids and solid materials.
Suitable for various corrosive and chemical applications, with high precision, remote signal output, PLC system monitoring.
Applicable measurement medium: Suitable for most liquid and powdery granular solids,
weak acids, weak bases, strong bases, and strong acids below 40%.
If in strong acid applications, anti-corrosion probes should be used.
Gasoline oil Diesel needs to choose explosion-proof function
In any of the following situations, pay attention:
Liquid/solid with foam There are strong voltage, strong current, strong electromagnetic interference around,
try to avoid high voltage, high current and strong electromagnetic interference
Steam and dust
Too high temperature and pressure
Measuring Range 5M, Blind Area: 0.4m
Measuring Range 8M, Blind Area: 0.4m
Measuring Range 10M, Blind Area: 0.5m
Measuring Range 12M, Blind Area: 0.5m
