CIXIFM P Series Low Flow Chemical Flow Meter Micro Flow Meter Liquid Mini Flow Meter

sales01@cxflowmeter.com

The flow meters of P series low flow chemical flow meter micro flow meters liquid small mini flow meter produced by Shanghai Cixi Instrument Co., Ltd. are all made of corrosion-resistant materials, resistant to acids, alkalis and various solutions, and are suitable
for accurate metering of various chemical medium and low viscosity that cannot be in contact with metals such as stainless steel. Used in the chemical industry or reactor flow monitoring.
Small vibration noise during working, convenient installation.


sales01@cxflowmeter.com
According to different media, the P series flowmeters have produced two types of flowmeters: one is used to measure oil, which is slightly cheaper, and the other is used to measure water,
liquid, chemical liquids, including corrosive liquids. Flowmeter, this price is a bit more expensive, but the overall is a very cost-effective liquid flow meter.

measuring water liquid
Shaft: Ceramic
O-ring: FKM; PTFE
Gear: special material, acid and alkali resistan
Clearance: Min clearance


for oil measuring
Shaft: SS304
O-ring: Nitrile/NBR (nitrile butadiene rubber)
Gear: Special resin
Clearance: normal clearance


P series gear flow meter

Model: CX-P1 (PS1)
K factor: 0.055 ml/P
Flow range: 1~100 mL/min
Gear material:  PPS
Housing material: PPS (PPS+SS316L)

Model: CX-P2 (PS2)
K factor: 0.175 ml/P
Flow range: 3~300 mL/min
Gear material:  PPS
Housing material: PPS (PPS+SS316L)

Model: CX-P3 (PS3)
K factor: 0.25 ml/P
Flow range: 5~500 mL/min
Gear material: PPS
Housing material: PPS (PPS+SS316L)

Model: CX-P4 (PS4)
K factor: 0.5 ml/P
Flow range: 10~1000 mL/min
Gear material: PPS
Housing material: PPS (PPS+SS316L)
Model: CX-P5 (PS5)
K factor: 2.5 ml/P
Flow range: 50~5000 mL/min
Gear material: PPS
Housing material: PPS (PPS+SS316L)

Product Characteristics

Power supply: DC5~26V
Measuring range: 1:100
Accuracy: 1~0.5 level
Temperature: -30~80℃
Pressure resistance: 8bar
Output: Square wave pulse (Hall sensor)

Can be integrated display or with DC8S remote digital display.4-20mA analog output,
Modbus RTU 485 communication, cumulative alarm, instantaneous alarm, etc.

Product Applications
The flow meters are all made of corrosion-resistant materials, resistant to acids, alkalis and various solutions, and are suitable for accurate metering of various chemical medium and low viscosity that cannot be in contact
with metals such as stainless steel. Used in the chemical industry or reactor flow monitoring. Small vibration noise during working, convenient installation.

If you want to know more, please consult winny:
sales01@cxflowmeter.com
