CX-FS-FE40 piston flow switch

CX-FS-FE40 piston flow switch

  •    Set range: See parameter list

        Accuracy: ±5%FS

        Delay:  Depend on the switch point , min. point 0.6L/Min

        Switch set scale: Calibrate it under the horizontal installation for water medium (20 C) .

       Installation position : The medium and the temperature will effect the switch value .

        LED display: Display the switch state , if the LED is directly current supply .

    INQUIRY

    Application

    CX-FS-FE40 type used for gas and liquid . Suitable for industrial automation / mechanical equipment/compressed air industry /refrigeration and air conditioning .

    Feature

    1,On-line installation  2,Mechanical type flow switch  3, Suitable for gas and liquid  4,Firm plastic, aluminum or stainless steel housing  5,Small pressure loss  6,Good repeatability and stain resistance  7,The mechanical part isolate from the electric part totally , it is economical type and suit for small flow range.  8, 3 times piston journey respond to original FE20 , which makes sure the high accuracy .  9, With switch setting scale ,so the used does not need to set in field . 10, LED display the switch state (option: double switch value output) .

    Technical data

    Set range: See parameter list

    Accuracy: ±5%FS

    Delay:  Depend on the switch point , min. point 0.6L/Min

    Switch set scale: Calibrate it under the horizontal installation for water medium (20 C) . Installation position : The medium and the temperature will effect the switch value .

    LED display: Display the switch state , if the LED is directly current supply .

    It will no LED display for AC supply .

    Connection: M12

    Output: Reed switch, capacity 24VDC / 250VAC ,100mA

    Pressure proof: 10bar(plastic),  50bar(aluminum),  100bar( stainless steel)

    Average pressure loss: 0.3bar( at 25L/min)

    Medium temperature: Max.90 Celsius degree

    Protective class: IP65

    CX-FS-FE40…GP material: Housing: POM plastic,

    Piston: POM plastic

    Reed switch: stainless steel

    Seal: NBR

    CX-FS-FE40…GA material : Housing: anode alumina

    Piston: POM plastic

    Reed switch: stainless steel

    Seal: NBR

Parameter list

Type
Pressure
Bar
Max.flow rate
L/min(water)
Adjustable range
L/min(water)
G
mm
L
mm
H
mm
B
mm
X
mm
Weight
Kg
FE40-008…L(X)008
50
40
0.6(0.1)..8(7)
G1/4
93
36
30
12
0.22(0.53)
FE40-010…L(X)008
50
40
0.6(0.1)..8(7)
G3/8
93
36
30
15
0.20(0.51)
FE40-015…L(X)008
50
40
0.6(0.1)..8(7)
G1/2
93
36
30
15
0.18(0.48)
FE40-020…L(X)008
50
40
0.6(0.1)..8(7)
G3/4
105
36
35
15
0.23(0.65)
FE40-025…L(X)008
50
40
0.6(0.1)..8(7)
G1
105
36
40
15
0.32(0.82)
FE40-008…L(X)015
50
40
1(0.5)…15(13)
G1/4
93
36
30
12
0.22(0.53)
FE40-010…L(X)015
50
40
1(0.5)…15(13)
G3/8
93
36
30
15
0.20(0.51)
FE40-015…L(X)015
50
40
1(0.5)…15(13)
G1/2
93
36
30
15
0.18(0.48)
FE40-020…L(X)015
50
40
1(0.5)…15(13)
G3/4
105
36
35
15
0.23(0.65)
FE40-025…L(X)015
50
40
1(0.5)…15(13)
G1
105
36
40
15
0.32(0.82)
FE40-015…L(X)025
50
40
2(0.8)…25(25)
G1/2
93
36
30
15
0.18(0.48)
FE40-020…L(X)025
50
40
2(0.8)…25(25)
G3/4
105
36
35
15
0.23(0.65)
FE40-025…L(X)025
50
40
2(0.8)…25(25)
G1
105
36
40
15
0.32(0.82)
FE40-020…L(K)070
50(100)
100
27(21)…70(66)
G3/4
105
36
35
15
0.23(0.65)
FE40-025…L(K)070
50(100)
100
27(21)…70(66)
G1
105
36
40
15
0.32(0.82)


            CXFE40-008… /CXFE40-010...


              CXFE40-015...


               CXFE40-020… /CXFE40-025...


    Note :

    1, The parameter in bracket is reset point, the parameter outside the bracket is action point .If the lower limit alarm (the monitoring flow rate is too small) ,at the time reference the reset parameter . If the upper limit alarm (the monitoring flow rate is too big) , then reference the action parameter .

    2, Under vertically installing on horizontal pipe , then test to get the above parameter for 20 Celsius degree water..



Installation                       wiring


Note : The installation position will effect the switch value .


Type selection sheet

CXFE40- 008 G D L 015 M 1
CXFE40-               CXFE40 series piston type flow switch
  008             G1/4
  010             G3/8
  015             G1/2
  020             G3/4
  025             G1
    G           Female screw
      D         DC 24V±20%DC
      J         AC 230V±15%AC
        S       Plastic housing
        L       Anode alumina housing
        X       Stainless steel housing
          008     Set range :0.6…8L/min
          015     Set range :1…15L/min
          025     Set range :2…25L/min
          070     Set range :27…70L/min
            M   M12
            Z   Direct cable
              1 1 switch point output
              2 2 witches point output


    1. It should mention the medium direction , medium ,pipe diameter and the expected set value ,when placing the order . Then we can set it before leaving factory .

    2,If the medium is viscous medium , please notice the viscosity , temperature and medium .

    3. If the medium is gas , please notice the pressure( meter pressure /absolute pressure) ,temperature and medium .


Optional accessory
ZL04- PU 02 M Z description
ZL04-         M124-core connector
SL04-         M12
  PU       PUR
    02     2m
    05     5m
    10     10m
      M   Female plug
        Z Direct type
        W Bend type
